Amazon Athena, a service that allows SQL queries to be run on data in Amazon S3, can be accessed through DBeaver. By leveraging the JDBC driver and AWS Single Sign-On (SSO), access to Athena can be managed with greater ease. The steps provided below will guide through setting up this connection.

Prerequisites

1. DBeaver: The DBeaver tool must be installed. Downloads are available here.
2. AWS CLI: AWS CLI is required for authentication via SSO. If not installed, follow the instructions here.
3. AWS SSO Configured: Single Sign-On must be set up for the relevant AWS account. Details on configuring AWS SSO can be found here.
4. Athena Access: The necessary permissions to query Amazon Athena and access S3 storage must be ensured.

Step 1: Configure AWS CLI for SSO

To authenticate using AWS SSO, AWS CLI needs to be configured first.

1. The following command should be run to start the configuration process: aws configure sso
2. Several prompts will appear, and the following details should be provided:
   • SSO Start URL: This will be the SSO start URL given by the organization (e.g., https://mycompany.awsapps.com/start).
   • SSO Region: The AWS region where SSO is active must be provided (e.g., us-east-1).
   • SSO User: The user will need to log in using their SSO credentials.
   • Profile Name: A profile name such as sso-athena-profile should be chosen.
3. Upon successful configuration, the AWS CLI profile will be linked to SSO, enabling authentication for future services.
4. To refresh credentials, the command below should be used: aws sso login --profile sso-athena-profile

Step 2: Download the Athena JDBC Driver

The Athena JDBC driver is required to establish the connection.

1. Visit the Amazon Athena JDBC Driver page to download the appropriate version.
2. The driver should be saved in an accessible location, as its path will be needed in the next steps.

Step 3: Open DBeaver and Add Athena Connection

1. DBeaver should be opened, and a new connection can be added by selecting Database > New Database Connection.
2. A search for “Athena” will display the option for Amazon Athena. If it doesn’t, the Add File option should be used to locate the previously downloaded JDBC driver.
   • Navigate to the directory where the JDBC driver was saved and select the .jar file.
3. After adding the driver, Athena should be selected, and the process can proceed by clicking Next.

Step 4: Configure Connection Settings

1. General Settings:
   • AWS Region: The AWS region where Athena data is stored should be selected (e.g., us-east-1).
   • S3 Staging Directory: Enter the path to the S3 bucket that Athena will use to store query results (e.g., s3://your-athena-results-bucket/).
2. Driver Properties:
   • OutputLocation: This should point to the same S3 bucket as the staging directory.
   • Workgroup: (Optional) Enter the workgroup if using a custom Athena workgroup.
3. AWS SSO Authentication:
   • In the Connection Settings, navigate to the Driver Properties tab.
   • Configure the following properties:
     • AwsCredentialsProviderClass: Set this to com.simba.athena.amazonaws.auth.profile.ProfileCredentialsProvider.
     • AwsProfile: Enter the AWS CLI profile name created earlier (e.g., sso-athena-profile).
     • AwsRegion: Specify the correct AWS region (e.g., us-east-1).
4. Test Connection:
   • The Test Connection button can be used to verify if the connection to Athena is successful.
   • If everything works, click Finish to save the connection.

Step 5: Query Data from Athena

1. Upon successful connection, the Athena database and its tables will appear in the DBeaver Database Navigator.
2. SQL queries can be run by right-clicking on the connection and choosing SQL Editor.
3. Data stored in S3 can be queried through standard SQL commands.

Troubleshooting

• Invalid Credentials: The credentials should be refreshed by running aws sso login if authentication fails.
• JDBC Driver Issues: Updating the JDBC driver often resolves compatibility problems.

Conclusion

By following the steps in this guide, a secure connection to Amazon Athena using DBeaver, AWS SSO, and JDBC can be established. Querying data stored in S3 can then be easily performed using DBeaver’s robust features.
